STAK összekötők / kiegészítők

EMC-optimised series connection according to IEC 60364-5-53

Details

STAK 2X16 for EMC-optimised series connection of lightning current and surge arresters according to IEC 60364-5-53.
lorem ipsum

STAK 25 Pin-shaped Terminal

Pin-shaped terminal for EMC-optimised series connection of lightning current and surge arresters according to IEC 60364-5-53.

1 Termék

Cikkszám 952589 STAK 25

GTIN 4013364132306, Vámtarifa szám: 85369010, Bruttó súly: 17.40 g, PU: 4.00 db.


Képek

További információ

STAK 25 pin-shaped terminal
Pin-shaped terminal for series connection to
surge protective devices up to 25mm²

Gyártó: DEHN
Típus: STAK 25
Cikksz.: 952589
vagy egyenértékű.

Tanúsítványok



Műszaki adatok

Nominal voltage (a.c. / d.c.) (UN ) 600 V
Max. PV voltage (UCPV) when used in combination with DEHNguard M YPV SCI ... 1200 V
Lightning impulse current (10/350 µs) 25 kA
Discharge current (8/20 µs) 50 kA
Cross-sectional area (min.) 1.5 mm2 solid / flexible
Cross-sectional area (max.) 25 mm2 stranded / 16 mm2 flexible
Type of connection front

A 952589 termék hozzá lett adva a jegyzettömbhöz.

A 952589 terméket hozzáadtuk a kosárhoz.

Webshop indítása

STAK 3X16 Pin-shaped Terminal

Pin-shaped terminal for EMC-optimised series connection of lightning current and surge arresters according to IEC 60364-5-53.

1 Termék

Cikkszám 900588 STAK 3X16

GTIN 4013364323933, Vámtarifa szám: 85369010, Bruttó súly: 40.00 g, PU: 4.00 db.


Képek

További információ

Pin-shaped terminal STAK 3X16
Terminal for series connection
Cross-sectional area: 3 x 16 mm2

Gyártó: DEHN
Típus: STAK 3X16
Cikksz.: 900588
vagy egyenértékű.

Tanúsítványok



Műszaki adatok

Nominal voltage (a.c. / d.c.) (UN ) 690 V / 1000 V
Load current at V-wiring 80 A
Lightning impulse current (10/350 µs) 25 kA
Cross-sectional area (min.) 1.5 mm2 solid / flexible
Cross-sectional area (max.) 16 mm2 stranded / 10 mm2 flexible
Type of connection front

A 900588 termék hozzá lett adva a jegyzettömbhöz.

A 900588 terméket hozzáadtuk a kosárhoz.

Webshop indítása

STAK 2X16 Pin-shaped Terminal

Pin-shaped terminal for EMC-optimised series connection of lightning current and surge arresters according to IEC 60364-5-53.

1 Termék

Cikkszám 900589 STAK 2X16

GTIN 4013364109339, Vámtarifa szám: 85369010, Bruttó súly: 20.00 g, PU: 1.00 db.


Képek

További információ

STAK 2X16 pin-shaped terminal
Double terminal for feed-through wiring
Cross-sectional area: 2 x 16 mm²

Gyártó: DEHN
Típus: STAK 2X16
Cikksz.: 900589
vagy egyenértékű.



Műszaki adatok

Lightning impulse current (10/350 µs) 25 kA
Cross-sectional area (min.) 2x 1.5 mm2
Cross-sectional area (max.) 2x max. 16 mm2
Type of connection front (double terminal)

A 900589 termék hozzá lett adva a jegyzettömbhöz.

A 900589 terméket hozzáadtuk a kosárhoz.

Webshop indítása
